Julius Keilwerth brass instruments
history, models and serial numbers
Toneking de Luxe, black and gold lackered
Julius Keilwerth is best known for his saxophones and there's a lot written about the Keilwerth saxophone history. But for quite some time Keilwerth also produced and sold brass instruments, mainly trumpets and trombones. On this page you'll find all the details I could find about Keilwerth brass production. On four separate pages I collected Keilwerth brass serial numbers 0 - 4.999, 5000 - 9.999, 10.000 - 14.999, 15.000 - 335308, and pictures, as a resource to unravel the Keilwerth brass history.
Keilwerth brass instrument production Keilwerth Blechblasinstrumente Produktion
Keilwerth brass instrument models Keilwerth Blechblasinstrumente Modelle
Keilwerth brass serial numbers: 0 - 4.999 : 5000 - 9.999 : 10.000 - 14.999 : 15.000 - 335308
Company history
Julius Keilwerth
Julius Keilwerth (12.04.1894 – 14.11.1962) first apprenticed for the Kohlert company in Graslitz, Czechoslovakia. After this apprenticeship, Julius Keilwerth and his brother, Max, established a workshop in their home around 1925. They primarily manufactured saxophones for Adler and F.X. Hüller. The Julius Keilwerth company was founded in Graslitz in 1925, when Julius started making alto and tenor saxophones. Once these two saxophone types were extremely successful, he began making sopranos, baritones and, upon special order, bass saxes.
Keilwerth factory in Graslitz
1930
Soon 100 employees worked in the Keilwerth factory, and an additional 50 were homeworkers. The Julius Keilwerth company became one of the largest saxophone manufacturers in Europe by the start of WWII, with approximately 150 workers.
After WWII the family was forced to leave Graslitz, like most of the German speaking population in Bohemia. Most people were only allowed to take 50 kg (110 lbs) of luggage on the train with them. Julius Keilwerth, then aged 52, is mentioned on an expulsion list for train 15, wagon 33, on Sept 12th 1946 destination Bavaria.
Julius Keilwerth first went to Nordhessen and in 1947 settled down in Nauheim, near Frankfurt. Other instrument makers also had settled down in Nauheim, due to an active policy of the local authorities. On January 29, 1947, the Julius Keilwerth Company started its operations in the laundry room of the Bäckerei (bakery) Stelzer at Bahnhofstrasse 9, Nauheim. There they employed 5 people, and did saxophone repairs only.
The old Julius Keilwerth production facilities in Graslitz, now Kraslice, in 1948 became part of the Czech Amati collective. Amati was a forged merger of all regional competitors. The first saxophones that Amati sold were still stamped with the "JGK - Best in the World" trademark, had the model name 'Toneking' and had Julius Keilwerth serial numbers.
In 1949, the Keilwerth company moved into a new building at Königstädter Strasse 101 in Nauheim. Later the company also opened and maintained a subsidiary division on Helwigstrasse in Groß-Gerau, 5km from Nauheim. In 1953 Keilwerth had some 50 people at work (home workers included), making not only saxophones but also trumpets and trombones, and repairing all kinds of wind instruments. Most of them were old employees from Graslitz. In 1956 a cheese-making in Groß-Gerau was bought to give room for the metal wind instrument making. In 1962/1963 the Offenbacher Architektengemeinschaft Novotny & Mähner designed and built a new factory at the Königstädter Strasse 103, four pavillons with an inner court. Here the operations from Nauheim and Groß-Gerau were brought together in 1964.
form. Keilwerth factory Königstrasse 103 Nauheim
By this time more than 80 people were producing saxophones and brass instruments.
In the early 1950s, a legal battle flared about who had the right to use the name Toneking and New King. Amati claimed in 1954 that they (also) had the right to use them, since they were the legal successor to the name, after their takeover of the Keilwerth company in Graslitz. Not only did Amati use the name Toneking, they also used the Keilwerth logo, as well as Keilwerth serial numbers. It took until 1955, for the European Court of Justice in The Hague to rule that Julius Keilwerth was the only one who could legally use the Toneking name.
Julius was helped along in his efforts by his son Josef (1919 – 1982), who was trained as woodwind instrument maker, as well as his brother—who was also named Josef, and had been the plant manager in Graslitz. His son Josef took over in 1962. After his death in 1982 Julius nephew Gerhard Julius Keilwerth (2.9.1945 - 24.2.2012) became manager at Keilwerth, together with his sister Christa. Gerhard worked for the company till 2007.
Gerhard Keilwerth in 2007
In 1989 Boosey & Hawkes purchased Keilwerth and merged the company with Schreiber in 1996. By then some 100.000 saxphones were produced. The combined company was sold to The Music Group in 2003. In 2006 The Music Group was broken up. Schreiber & Keilwerth became an independent company. The Keilwerth production moved to Markneukirchen under sharp protests from the workforce, the administration remained in Nauheim. In 2007 Gerhard Julius Keilwerth left the company and started a saxophone workshop at Königstrasse 101 in Nauheim. In March 2010, Schreiber & Keilwerth filed for insolvency. On 1 August 2010 they were subsequently acquired by Buffet Crampon.
The Nauheim headquarter at the Industriestrasse that was
abandoned in 2010
Keilwerth brass instrument production
Keilwerth is believed to have started brass production in the 1950's,after Julius had moved to Nauheim. Nevertheless a Jul. Keilwerth trumpet from Graslitz appeared on German Ebay in 2015. It has valves numbered 52, 53, 54 and the little anchor that is the trademark of Graslitz based Bohland & Fuchs, another company that was integrated in the Amati collective. Graslitz was named Kraslice after the war so this must be a pre-war trumpet.
I
source: Ebay.de
It might be the only known pre-war Julius Keilwerth brass instrument.
In the early 1950s, in addition to their saxophones, Keilwerth started producing their own trumpets, trombones, and at some point also cornets and flugelhorns. In a 2004 Gaby Kerrmann from the marketing department of The Music Group, in an e-mail to Glenn B. Howell, states that Keilwerth made trumpets from 1955 till 1980. That they already had started in 1955 is confirmed by this letterhead from March 1995, were Julius Keilwerth presents itself as maker of saxophones ánd of jazz trumpets and jazz trombones.
This particular letter was directed to the Patent Office, Keilwerth claimed an innovation that made the three valves of a perinet valve block interchangeable. The patent was granted. The interchangeable valves were applied in the Super de Luxe serie. From the first ones onwards, they have the air flow to the bell spring from the right hand side of the first valve (where the other models have the air flow form the left hand side). This made it possible to use identical valves in all the valve casings with the position of the valves rotated in the different valves. Below a few pictures, courtesy of Janis Edvards Strupis, that illustrate the point. As far as I know the Super de Luxe trumpets don't have numbers on the valve casings and on the respective valves anymore, as there is no need to make a difference any longer.
.JPG)
.JPG)
.JPG)
All three valves are identical. The red arrows show the different locations where the nipples enter
50's
Catalogs give a little insight in brass production from 1955 onwards. There is a 1958 catalog, in English, maybe targeted at the US market, with models named De Luxe, Toneking and Super de Luxe.
Keilwerth catalog 1958
A 1959 catalog in German shows a cornet and trombone on the cover and a trumpet and trombone with their cases. I haven't found the instrument pages yet.
Keilwerth catalog 1959
60's
There is a catalog dated March 1967. Here prices of the cases (the only thing I can compare) are up some 25%.
Keilwerth catalog,
March 1967, coll. Gerard Westerhof
Some interesting details: it has the same model names, although there are two versions of the Toneking, the normal one and an improved one with two waterkeys and a ring on the third valve loop. Another novelty is the black-and-gold option that is offered for the Toneking and De Luxe models (as well as for the Toneking and New King saxophone models.) Priced some 60 DM above the basic model.
Keilwerth catalog, Januar 1969
Almost the same catalog (a few pages more) from Januar 1969 has prices that are 10% up. The reason: the introduction of a 10% VAT in Germany on 1-1-1968. The black-and-gold versions are there but no longer as a novelty.
Gaby Kerrmann from the Keilwerth marketing department in 2004 came up with some pages of what I suspect is the same catalog, she said was probably from the late sixties. It has handwritten prices, that are approximately half of the printed prices above. The printed prices are for consumers (as VAT is explicitly included), maybe the handwritten prices were meant for the retailers.
Keilwerth catalog, late sixties source: Gaby Kermann, Keilwerth
70's
The actual Keilwerth website states that 'by 1970, the company had begun concentrating on the production of saxophones only'. The German version said it even more definite: '1970 stellte Keilwerth den Bau anderer Instrumente vollendst ein und stellte von nun an nur noch Saxophone her.' Saxophonist Helen Kahlke from Canada shows on her website a catalog with a price list dated March 1979. The catalog features different musicians, like Gerd Köthe from rock band Joy Unlimited, (as of 1970, making albums from 1970-1974), and Robert Weidmann with Swiss Dixieland band P.S. Corporation (playing together on albums in 1975 and 1977), so I guess we should date it somewhere between 1975 and 1979.
Keilwerth price list March 1979
Toneking, De Luxe 2000 and Super de Luxe 2000 are the model names for trumpet, cornet and flugelhorn, De Luxe 2000 and Super de Luxe 2000 the trombone models in this catalog. Although for sax and flute a Student model is listed, there is no brass with this name. The list states the prices for retailers (Netto-Einkaufspreise). Comparing the (late) sixties catalog with the ca. 1979 one shows us that a gold lackered Toneking trumpet went for DM 114 in the sixties, in the 1979 catalog it was priced DM 244. Assuming that the handwritten prices in the sixties catalog also are meant for the retailers, the difference would be more or less in line with inflation rates. Note: the catalog explicitly states that the Böhm metal flutes in C 'Julius Keilwerth made in USA' are made in Elkhart/USA for Keilwerth. Nothing about other instruments being foreign make.
80's
Keilwerth flyer ca. 1980's coll.:Gerard
Westerhof
An undated leaflet sold on Ebay by a Polish seller in October 2014, advertises the Keilwerth Student model. Besides trumpets there are saxophones, trombones, clarinets and flutes of the Student model offered. The leaflet went together with two other leaflets, one for 'Toneking' and one for 'Toneking Exclusive' saxophones. The Exclusive model came in 1982 as topmodel, so these leaflets should be from that period of time. I don't know if this was the complete Keilwerth brass program at the time, there are Toneking and Toneking de Luxe trumpets in the same serial number range.
Trompetenforum member 'Guenni' in 2005 also said he had a Keilwerth flyer from the early eighties with the trumpet program, where the Toneking de Luxe 2000 was the top model. Trumpetherald member 'Gus' even stated in 2003 to have a catalogue from 1988. 'Gus' visited the factory in 1989, bought a trumpet and talked with Mr Keilwerth III (this must have been Gerhard Julius Keilwerth) who told him that Mr Keilwerth I started in Jugoslavia (should be Czechoslovakia, ed.) and after the war they moved to Germany. At that time Mr. Keilwerth III told him that they were cutting trumpet production to concentrate in sax. There is a Student trombone that was bought in December 1989.
But, as Gus said: "I do not know if the trumpet is a true Keilwerth". Although Keilwerth sold trumpets in the 80's, it's pretty sure that they didn't make them anymore by then.
Note: in the 70's catalog Toneking and 'Julius Keilwerth' are marked as a registered trademark (®) , in the 80's catalog 'Julius Keilwerth' is a registered trademark. In the 60's catalog the JK logo with the crown is used prominently, in the 80's the crown still appears on instruments but without the JK.
Rare birds
There are a few rare Keilwerth birds that have a date as well. First the Keilwerth Toneking 3000 Jazzophon, a sax shaped trumpet. In an e-mail from Gerhard Julius Keilwerth to Jim Glass in 2009/2010 about the production of the Keilwerth Toneking 3000 he dates these between 1982 an 1986:
"I devised this instrument, which is a normal B-trompet in manner of a saxophon. It was built from 1982 to 1986. I can’t tell you an exact number of items, but there where not more than 100. And as far as I know there where unfortunately no famous musicians who played it.”
Keilwerth Toneking de Luxe 3000 Jazzophon sr.nr. 306856
Funny thing is that at the same time Keilwerth marketed a straight alto saxophone also branded Toneking 3000. The ultimate inversion....
Uwe Ladwig, in his book 'Saxophone', on the other hand states that the Toneking 3000 was made in the seventies. His source, he says, was also Gerhard Keilwerth. Maybe both statements are true, as there is quite a gap between the serial numbers of the several Toneking 3000 instruments, see below. The one with serial number 27963 seems to be an outlier, the other known instruments having serial numbers 306856, 312250 and 312600. Those numbers fit well in the 1982-1986 (Blessing) period and the Toneking 3000 name is congruent with the Toneking 2000 series of that time. The 27963 has a lot of similarities with the other Keilwerth instruments in that number range, so it might be made in Nauheim, whereas the others might be of Blessing origin.
In the 60's Keilwerth also made a Dizzy Gillespie style trumpet for Dizzy, according to Janis Edvards Strupis from Australia, who remembers that there was a flyer showing Dizzy and this trumpet coming with his 1966 Super de Luxe Keilwerth.
One other 'dated' Keilwerth instrument is a sousaphone, the only one so far known to bear the name Keilwerth. It was built in 1978 and is engraved: „ESPECIALLY MADE FOR JOHN ARTHY BY Julius Keilwerth NAUHEIM 20.1.1978“. Arthy was a founder, bandleader and bass player of the British Pasadena Roof Orchestra. He sold it in 1986 to a Swiss gentleman who sold it in May 2014 on a Swiss auction site for 510 Swiss Franks. It is suggested on Tubenet that it might be a Böhm and Meinl stencil. It has serial number 77539 and that would fit reasonably in some other known B&M numbers. Böhm and Meinl was company established in 1948, in Geretsried, near München, which was purchased in 1992 by Walter Nirschl. They made B&M-branded instruments in both the German and American styles, and also made York Master and many Marzan-branded instruments.
Keilwerth sousaphon especially made for John Arthy, 1978. Source: Ricardo.ch Right: Bohm & Meinl sousaphon, source: HUC
Horn-u-copia also mentions a 'Keilwerth' soprano trombone (or slide trumpet) without futher details.
Keilwerth brass instrument models
The catalogs and the information collected in the serial number list below gives the following overview of Keilwerth brass instrument models. Keilwerth didn't make rotary valve instruments and no other brass instruments than trumpets, cornets, flugelhorns and trombones.
The main brass model names were the Toneking, the (Toneking) de Luxe and (Toneking) Super de Luxe, later with the '2000' extension.
|
Keilwerth brass instrument models (and some saxophone models as a reference)
|
||||||
|
|
early years, 1955 onwards |
1958 catalog |
1967/1969 catalog |
1979 pricelist |
1980's flyer | other |
|
Trumpet |
Toneking |
Toneking |
Toneking |
Toneking |
Student | Modell AT |
|
|
Toneking de Luxe | Modell ST (as of 1989?) | ||||
|
|
De Luxe |
De Luxe |
De Luxe |
De Luxe 2000 |
Toneking de Luxe 2000 | |
|
Super de Luxe |
Super de Luxe |
Super de Luxe |
Super de Luxe 2000 (Bb&C) |
Toneking Super de Luxe 2000 | ||
|
The New King |
Julius Keilwerth | |||||
| Superba 1 (somewhere between 1965 and 1986) | ||||||
| Superba 2 ( between 1965 and 1986) | ||||||
| Toneking de Luxe 3000 (Jazzophon) | ||||||
| Toneking Exclusive | ||||||
|
Cornet |
Toneking |
Toneking |
Toneking |
|
Julius Keilwerth | |
|
|
|
De Luxe |
De Luxe |
De Luxe 2000 |
Toneking de Luxe 2000 | |
|
Flugelhorn |
|
Super de Luxe 2000 |
Toneking Super de Luxe 2000 | |||
|
Trombone (slide) |
The New King |
Toneking |
Toneking |
|
Student | Modell ST (as of 1989?) |
|
|
The New King de Luxe |
De Luxe |
De Luxe |
De Luxe |
Modell SX (as of 1989?) | |
|
|
Super de Luxe |
Super de Luxe |
Super de Luxe |
Super de Luxe 2000 |
Toneking de Luxe 2000 | |
|
|
|
|
|
Super de Luxe 2000 R (with rotary valve) |
Toneking Super de Luxe 2000 | |
|
Trombone (valve) |
Toneking de Luxe |
De Luxe |
De Luxe |
|
||
|
|
|
Super de Luxe |
Super de Luxe |
Super de Luxe 2000 |
Toneking Super de Luxe 2000 | |
|
Trombone (valve and slide) |
|
Toneking Super de Luxe | ||||
| Saxophones * | ||||||
| Graslitz, 1940's | Nauheim, 1960's | 1979 | 1980's | other | ||
| King | Student (as of 1968) | Student | ST90 (as of 1991) | |||
| The New King | The New King (till 1970) | Toneking | Toneking | EX90 (as of 1988) | ||
| Toneking | Toneking | Toneking Special (late 60's onwards) | Toneking Special | Toneking Exclusive (as of 1982) |
SX90 (as of 1988) ST90II (as of 1992) |
|
| Toneking Solo |
P.Ponzol (as of 1987) SX 90 R (as of 1993) |
|||||
* the discussion about the system and the logic in Keilwerth sax modell names is a difficult one.
There are a few examples of a The New King trumpet (with early serial numbers: 0048 and 1468 or without). These have quite a different engravings, the one flowerish, the other straight. They seem to be the quite similar to the early Toneking instruments and untill now are only found in UK and Australia. I also found a reference to a Julius Keilwerth The New King de Luxe trombone and a The New King trombone with serial number 21. The New King was a model name used for JK saxophones from before WWII until 1970.
There are quite a few Keilwerth 'Student' trumpets and 'Student' trombones known. The Student instruments are described as the most economically priced model in the Julius Keilwerth program, and therefore especially suited to students and beginners. The Student saxophones and flutes (but no Student trumpet/trombone) appear together with De Luxe 2000 and Super de Luxe 2000 instruments in the catalog with the 1979 pricelist. The Student model in saxophones is dated between 1968 and 1988 by Uwe Ladwig. In the 1980's flyer Student trumpets, trombones and saxophones and flutes are offered. Although serial numbers for Student trumpets and trombones are in between those of the Toneking and the Toneking 2000 series, I believe they were made in the 80's, after the Toneking (de Luxe) 2000 instruments. I believe both the Student and the Toneking 2000 instruments were supplied by other makers than Keilwerth, using the serial numbers of those makers. For the '2000' instruments that maker probably was Blessing, they are pretty identical to the Blessing Scholastic. Like the Toneking de Luxe 2000 cornet. The Blessing serial number list would date that one to 1971. For the Student instruments I'm not sure but B&S/Weltklang might be a candidate. The Student saxophones in the 70's and 80's were first made by Amati, and then by B&S, according to Helen Kahlke.
A trumpet, a trombone and a flugelhorn are just named 'Julius Keilwerth'. They are amongst the latest Keilwerth brass instruments
Then there are rare examples named Modell AT (trumpet) Toneking Exclusive (trumpet) and Modell SX (trombone). A Modell ST trumpet was bought in 1990, a ST trombone was mentioned in a Spanish Ebay-ad. Exclusive, SX and ST were also saxophone model names from the end of the eighties, for the AT model name I have no clue.
The Keilwerth instruments were for a long time marked 'Made by Keilwerth, Germany' and not 'BRD' or 'West Germany'. The use of BRD was discouraged by the authorities of the Federal Republic of Germany itself, because it was considered to be derogatory (GDR) jargon. The term was not banned by law, but its use was discouraged. The trumpets in the 200.000 range are marked Julius Keilwerth W Germany. In 1973, the Bundesgerichtshof made a ruling that Made in Germany does not enable people to properly distinguish between the two Germanys of the time, so 'Made in West Germany' and 'Made in GDR' became popular.
Design: King Super 20 replica
The Keilwerth (Toneking) de Luxe trumpet seems to be a replica of the late 40's H.N. White Cleveland King Super 20 trumpet, which according to some sources was admired by Julius Keilwerth. The King Super 20 trumpets appear in the H.N.White catalog as of 1946 and remained unchanged until the company was sold in 1965.
Keilwerth De Luxe ca 1955 serial number 1104
King Super 20 Symphony Silversonic 1966 serial number 415937,
Keilwerth Toneking de Luxe ca 1965 serial number 12369
The Keilwerth trombones are stated to be Olds clones.
Keilwerth stencils branded otherwise
Keilwerth used at a certain point instruments made by others, but they also made/sold instruments that were marketed under different other names, so called stencils. These instruments were mainly sold in the VS and Canada.
A 'Made by Keilwerth' trumpet branded Kenwood, was sold on Ebay in 2014. It has the valve bow and guide of the early 'no serial' Keilwerth trumpets and valves numbered 13,14 and 15 which makes me believe it's one of the oldest Keilwerth stencils. ,
Kenwood valves numbered 13,14,15 source Ebay.com 2014
A 'Made by Keilwerth Germany' trumpet with serial number 2058 is marked Van Hall. It's identical to the Keilwerth Toneking. The serial would date it around 1960.
.jpg)
.jpg)
Van Hall trumpet Made by Keilwerth Germany, coll. Kaleb Hagel, Canada
It's not clear from where the trademark 'Van Hall' comes. There is a Kurath (Pre Willson) Silver 3v BBb tuba stencilled as a Van Hall. Kurath started in 1950, and Van Hall 'made a load of bad instruments in Holland' according to a source. There are several Van Hall (alto and tenor) saxophones, made by Keilwerth with serial numbers dating them to 1968 - 1976. They often are named 'Van Hall Luxor'. Luxor was in the mid seventies/early eighties a German label for instruments sourced from various makers and countries. Keilwerth made saxophones for Luxor, according to Keilwerth (Gabi Kermann). The above non-Luxor Van Hall would be from an earlier date.
Another 'Made by Keilwerth Germany'trumpet, serial number 5345, bears the model name Kembro. It's identical to a Toneking.
Kembro trumpet Made by Keilwerth Germany, source Ebay 2017
Hamilton
Some instruments 'Made by Keilwerth' are marked 'Hamilton'. The one with serial number 22318 was purchased from Grossman Music Corporation in the early 1960s, according to Horn-u-Copia. Hamilton was a trade name of Grossman Music Co., a musical instrument distributor based in Cleveland Ohio. It was founded by the brothers Henry and Julius as Grossman Brothers in 1922 to distribute 'only Stringed and Band Instruments'. The serials of these Keilwerth Hamiltons, betweeen 18.3xx and 22.3xx nicely fit into the Keilwerth range, albeit that they would have been made around 1970 and not in the early 60's. There are other Hamilton trumpets mentioned on Horn-u-Copia and Trumpetherald.com with serial numbers in the 55.000-60.000 range, a HUC Hamilton with serial 142.755 and one on Ebay with serial 717.533, obviously from other suppliers. The Hamilton Supreme is stated to be similar to the Blessing Standard. Some known serial numbers of cornets and trumpets in the 59xxx range and dating of these to the early fifties is consistent with the Blessing serial numbers, but another Hamilton Supreme with serial nr 16448 is not.
Hamilton Supreme trumpet and cornet from 1953 Grossman catalog
La Sete
And there are 'La Sete' trumpets 'Made by Keilwerth Germany'. Those also appear to be stencils for the US market, a practice well known from the Keilwerth saxophones. La Sete is believed to have been the house brand of the Barthold brothers music store chain in Southern California, it was also used by Splevins Music Center, 8834 W. Pico Boulevard of Los Angeles, selling band instruments and dissolved in 1967. (The LA in La Sete could thus refer to Los Angeles. 'Sete' is also found as Séte and Seté). The La Sete trumpets in the 18.000 - 22.000 range definitely are Keilwerth instruments, as they are marked 'Made by Keilwerth Germany'. In the lower serial numbers (500-1800) there are instruments 'Made by Keilwerth' but also instruments 'Made in Germany' that are identical to the Wohlrab 8N and 15N model. Splevins also sold a La Sete engraved trumpet 'Made by Wohlrab Germany'. Wohlrab is believed to be a trademark from another Nauheim company, Bauerfeind. (Bauerfeind builds valvesets and had a mr. Wohlrab making their trumpets). There are several La Sete trumpets (in the 7000 range) marked only "Made in Germany". My guess is that they are also from Bauerfeind as they have a lot similar with other Wohlrab instruments. Then there are La Sete trumpets from 'Elkhart, Ind.", with serials in the 150.000 range. So while there were a few 'real' Keilwerth trumpets sold under the La Sete brand, like Hamilton they sourced from other makers as well.
And by the way, Elkhart, Indiana is where Blessing produced their trumpets, the company that provided Keilwerth with trumpets in the later years. The La Sete instruments from Elkhart are pretty similar to those Blessings/Keilwerths.
Keilwerth also produced/sold instruments under the Crestone brand, mainly saxophones. These seem to have been sold in the fifties in Canada, according to a thread on Trumpetmaster. There are also trumpets and cornets with the Crestone brand: a pre 1954 Crestone cornet is reported, with 'Germany' on the valves but not 'Made by Keilwerth' and a trumpet 'Made in Germany' with serial number 5611574. There also was an Eb tuba with the Crestone label sold through Canadian auction site Kijiji in 2014, reported to be 'made by Keilwerth' and 'made in the sixties'. I think these were not made by Keilwerth.
.jpg)
.jpg)
Crestone
Eb tuba, Made by Keilwerth, in the sixties,
And then there's a connection to Hopf. Horn-u-Copia states that Hopf in 1948 fled the Graslitz region and relocated in Taunusstein-Wehen under the name Willy Hopf & Co. They started making woodwinds after the relocation. For brass instruments, they stencilled the products from their peers from the former home country. "The top line came from Keilwerth", according to Horn-u-copia. That's confirmed by a statement of Gerhard Julius Keilwerth, who is quoted on the Markneukirchner Museum forum saying that a Hopf New Sound trumpet was built by Julius Keilwerth somewhere between 1965 und 1973.
But as the Hopf New Sound may look quite a lot like the Keilwerth Super de Luxe with it's brass bows, there are a lot of differences; the Hopf has a hexagonal moutpipe reciever and water key, a different 3rd slide ring, the Keilwerth Super de Luxe has a micro tuner, a bell ring and two brackets in the tuning slide. And the Hopf New Sound instruments don't have a serial number as far as I know. One of them has valves numbered 169,170,171 which doesn't point in the Keilwerth direction either. Norbert Böpple (www.jbs-brass.de) told forum member Rainer H. that the Hopf was completely built bij Bauerfeind for Keilwerth and then traded to Hopf. That seems to be more accurate: traded by Keilwerth but not built by Keilwerth. The Hopf New Sound turns out to be identical to certain Wohlrab instruments (Symphonic S), Wohlrab being a Bauerfeind trademark.
Hopf & Keilwerth: different:
Hopf New Sound
Keilwerth 11547 Super de Luxe
Wohlrab & Hopf: identical:
Hopf New Sound 2002 de Luxe
(Curt Wohlrab jun. managed a music shop, Musik Haus Wohlrab GmbH, after WWII. It was located at the address Hauptstrasse 182 in Heidelberg, before the war the address of a jewish owned umbrella shop Frank und Cie. Curt Wohlrab acquired patents for his valveless trumpets in Germany and the USA. Bauerfeind had a man named Wohlrab building their trumpets. I guess Curt Wohlrab later on worked for Bauerfeind or cooperated with them and gave his name to the Wohlrab instruments.)
A trumpet marked Keytone Rexton is, according to the Ebay seller, also a Wohlrab and identical to the Hopf New Sound.
Keytone Rexton (source Ebay2015)
There are also 'Keytone Solist the Luxe' and 'Keytone Gold Star' trumpets that are identical to Wohlrab/Bauerfeind instruments.
An interesting Keytone with the engraving '10 april 1958 PO USA - 3298 Special Services Property' added has similarities with some early Keilwerth trumpets but also differences. It has no serial number and valve numbers 79, 80, 81 indicating a Graslitz provenance.
(Special Services were the entertainment branch of the US Army)
Both Bauerfeind and Keilwerth were located in Nauheim, I can't rule it out but for now I don't assume a direct relation between Keytone and Keilwerth.
There's a Toneking from Musik Barth in Stuttgart with the JK logo, bought new in 1958, with totally different details.
And there's a Toneking (sr.nr. 1690) with an A and H added to the logo on the bell. That makes it read like AKH, suggesting A.K. Hüttl, another Czech/German instrumentmaker. This instrument was sold on Ebay in 2014 by a Detroit saxophone shop. The seller added that "Rumor has it that this horn was sent back from Germany with Detroit clarinetist and Herb Couf, who eventually stenciled Keilwerth saxophones. We can neither confirm or deny the story". .....
Superba 1 and Superba 2
In an auction from 2012 a Keilwerth Superba 1 is offered. This trumpet has a pinky hook that looks familiar from older Keilwerths and looks like a Toneking. Another Keilwerth Superba 1 was bought second hand in 1978, serial number 25868 and has the same pinky hook and valve caps but braces in the main tuning slide and a second valve adjustment handle. It states 'Made exclusively for H.Couf by Julius Keilwerth West Germany'. It looks a lot like the Keilwerth Super de Luxe model, but with Blessing like valve caps. In 2018 a Superba 2 made by Keilwerth for H.Couf was offered on Ebay, serial nr. 18254, it looks similar to the afirst mentioned Superba 1 and thus to the Toneking Model. An H Couf Superba 1 flugel that's mentioned on Trumpetmaster with serial number 265647 might be from a different maker ('Conndirectorfan' lists it as a Blessing).
Herbert "Herb" Couf (February 15, 1920 – July 8, 2011 in Michigan) was an American clarinetist, saxophonist, composer, music store owner, music instrument manufacturer executive, and an importer of music instruments. He was based in Michigan and that's were all (or most) of the brass Superba's are found. The Superba model name is also used for saxophones that were made by Keilwerth for Couf. From 1965 to 1986, Herbert Couf, then president of the WT Armstrong company, had three Keilwerth models stencilled for him under the model name "H-Couf": the "Superba I", "Superba II" and "Royalist". These instruments were built in Germany and mainly corresponded to the Toneking Special (Superba I), Toneking (Superba II) and New King (Royalist).
Keilwerth Superba 1, source Heritage Auctions 2012
.jpg){kind=small}
Keilwerth Superba 1, Made exclusively for H.Couf by Julius Keilwerth West
Germany, serial nr 25868
Keilwerth Superba 2
Made exclusively for H.Couf by Julius Keilwerth West Germany,
serial number 18254 source Ebay.com 2018
Stencils marked Keilwerth: Blessing
Keilwerth Super de Luxe 2000 flugel serial nr. 240409 (source: Ebay) Blessing Artist flugel serial nr. 251636 coll. Peter Willemsen, Nld.
Blessing Scholastic serial nr. 248466 Keilwerth De Luxe 2000 serial nr. 241655
Blessing Scholastic serial nr. 244980
Keilwerth Toneking de Luxe serial nr. 240976
Blessing Scholastic serial nr. 376xxx
Keilwerth Toneking Super de Luxe 2000 serial nr. 227291
Other evidence can be found in the serial numbers (see serial number pages). Keilwerth brass instrument
numbers make a sudden jump, first to the 100.000 range, with mostly 'Student'
instruments and then to the 200.000 range with the 'De Luxe 2000' and 'Super de
Luxe 2000' models like the above flugelhorn. The 6-digit serial numbers
in the 200.000 range fit very well in the
Blessing serial number list; Blessing reached those in the
seventies. The 220.xxx to 330.xxx numbers would then place production of these
Keilwerth instruments (most of the Jazzophons included) in the 1975-1983 range
(from 1983 Blessing is said to have used a prefix to their numbers).
The Keilwerth Toneking De Luxe 2000 would thus be a Blessing Scholastic, with
identical design, valve block,valve caps ..... Blessing is said to have produced
also for other German sellers in the 70's and 80's. So based on the serial
numbers one could assume that Keilwerth bought their brass in
Elkhart from 1975 till 1980. A little more research is
needed to get the models sorted out.....
Stencils marked Keilwerth: the 100.000 range
I'm less certain about the 100.000 range. So far I discovered instruments with 6 digit numbers between 108.000 and 125.000 (and one with a 99.000 number). Like the 200.000 upwards instruments, they don't have the hexagonal valve caps and bottoms (the latest are to been seen on trumpets with a 46.xxx number). If these were Blessings they would have been produced between 1962 and 1964. That's not plausible, Keilwerth were making their 5 digit instruments untill at least 1970, according to the sparse available data. All of the "Student' branded instruments with a serial fall in this 100.000 range. Some of the Student instruments have a three or four digit number, occasionnaly with a letter added. That's a way valve blocks were marked in the Markneukirchen area, which would suggest these instruments were made in Germany. For now my hypothesis is that these instruments (at least part of them) were provided bij VEB B&S in Markneukirchen/Klingenthal. They made amongst others the Weltklang and Bandmaster instruments, on these instruments similar three or four digit numbers with a letter are found, indicating the maker of the valve block. The (sparse) serial numbers on the Student instruments then would come from that East German company. Based on the catalogs above my other hypothesis is that they date from the (early) 80's. According to Uwe Ladwig,
the saxophone Student models were built in the 70's and 80's, first by Amati, then by B&S, then by Amati again and finally by Jupiter. Serials numbers known here are 05441, 05535
York
In 2001 Schreiber-Keilwerth built a new factory in Markneukirchen for the production of wind instruments and brass instrument parts.
They made parts for the British Besson instruments and Boosey and Hawkes Sovereign cornets (amongst others?). As of 2006 Schreiber-Keilwerth entered the brass marked again with a line of instruments under the York brand, completely manufactued in Markneukirchen. The line up consisted of 24 instruments, based on two formats, the 'Preference' and the 'Eminence'. Here's a
York catalog of those days. They were descendants of the former Besson ranges (Schreiber already had all the requisite tooling etc because of the break up of Besson), but the company claimed there had been major improvements, refinements and enhancements, as well as cosmetic changes to the all new range. They started producing a 'Preference' and 'Eminence' model cornet and euphonium as well as 'Preference' flugelhorn, tenor horn, baritone, EEb tuba and BBb tuba, with the possibility of additions to follow. No trumpets or trombones, as far as I'm aware of. The York line failed to find their place in the brass band world and was discontinued when Buffet-Crampon acquired Schreiber-Keilwerth in 2010.
York
cornet by Schreiber-Keilwerth, 2006
Not Keilwerth: Toneking by Amati
There are some Toneking trumpets without the Keilwerth logo, saying 'Made in Czechoslovakia' on the leadpipe. Sellers state that these are Amati trumpets, which could be true. Amati used the name Toneking, until the legal battle with Keilwerth ended in 1955 with Julius Keilwerth as winner. Maybe this trumpet dates from that period, but it might also be newer, as the case looks more 70's/80's.
Amati Toneking trumpet, 'Made in Czechoslovakia' in 2014 offered on the Mexican auction site Mercado libre
Another Toneking, valves numbered 52,53,54, 'Made in
Czechoslovakia' source Ebay.com 2018
Interesting is that on the justanswer site someone mentions a Toneking trumpet that has the word Bohemia on it. That would date it even before 1918, when Bohemia became part of the new post WWI state of Czecho slovakia. The expert on the site answers that the piece is circa 1890-1915 and that the brand was only around for about 6 years.
Not Keilwerth: Toneking by New York Band Instrument Co.
The name Toneking is used by other makers as well, having no known relation with Keilwerth. It was for example the house brand of the New York Band Instrument Company from East 14th Street, New York.
.JPG)
.JPG)
They used it for different instruments, like cornets, trumpets, french horns, (valve) trombones, mellophones but also ukeleles and banjos. New York Musical Instrument Co started as dealers and importers in 1915, later changed their name to New York Band Instrument Co and reportedly went out of business in 1950. So there's no reason to suppose a relation with Keilwerth. Horn-u-copia.net lists several NY Band Company instruments.
New York Band Instrument Co. brass instruments source: Horn-u-Copia.net
A New York Band Instrument Co. Toneking in Bb/A has written Czechoslovakia on the mouthpiece reciever. It also has a small circle with extensions on the middle valve.
New York Band Instrument Co. Toneking in Bb/A, valve numbers 94,95,96, source Ebay.com 2015
Not Julius Keilwerth: Josef Keilwerth
There are some trumpets around marked Josef Keilwerth. Josef Keilwerth was an instrumentmaker in Graslitz. He was born in 1887, a few years after Johann Baptist, the father of Julius. Josef Keilwerth lived and worked at the Berggasse 736 (now Na Kopečku 736, Kraslice). In August 1946 he was expelled like most of the German population in the former Sudetenland after WWII. He was listed to leave by train to Bavaria, together with his wife Anna and daughters Margaretha and Gertrud. These instruments are to be dated before WWII because they have the German name for Kraslice. 736 is the house number.
| Josef Keilwerth trumpets | ||||||
|
|
engraving |
year (as stated by owner or seller) |
remarks |
thumbnail picture |
source |
|
|
|
Jos. Keilwerth 736 Graslitz C.S.R |
1918-1938 |
piston trumpet |
|
|
Horn-u-copia |
| Josef Keilwerth 736 Graslitz | before WWII | rotary valve trumpet | Answers.com | |||
| Josef Keilwerth Graslitz 736 | pre WWII | top action rotary valve trumpet, gold washed 4-3/8" bell |
 |
 |
Ebay.com sept 2014 | |
Keilwerth brass mouthpieces
Left a 1958 traditional trumpet mouthpiece, middle the characteristic shape of the later Julius Keilwerth trumpet mouthpieces; to the right a ca. 1958 trombone mouthpiece and a newer one..
Keilwerth brass serial numbers
Keilwerth brass serial numbers are on four separate pages: serial numbers 0 - 4.999 : 5000 - 9.999 : 10.000 - 14.999 : 15.000 - 335308,
There are serial number lists of Keilwerth saxophones around but there was no such thing for their brass instruments. On these pages you'll find a list of instruments and numbers that were traded through Ebay, Quoka and such, information provided by owners of Keilwerth brass instruments, with information added from sites like Trompetenforum.de (where Brigantiumjazz triggered me to make this list), Trumpetherald.com, Trumpetmaster.com, Horn-u-copia and the Yorkmaster public pictures at Yahoo. There seems to be no relation whatsoever between the serial numbers of Keilwerth saxophones and their brass instrument serial numbers.
The serial number list of brass instruments has almost 700 entries, that's maybe 1 percent of Keilwerth brass production. It shows a fairly continuous serie up to number 30658, with dozens per thousands in the first 10.000, and a little less per thousand in the next range. Then, after a few incidental Tonekings, new models show up, like the 2000 and 3000 series and the Student. The jump, first to the 100.xxx range, with mostly 'Student' instruments and then to the 200.xxx range with the 'De Luxe 2000' and 'Super de Luxe 2000' models must originate in other makers providing the instruments. Here the gaps between the numbers are much larger. That's probably because they are part of a serial number list that includes the makers 'own' instruments (and maybe other stencils by the same maker). And maybe also because these are newer and more of them are still with their original owners, so they down't show up on Ebay and other sites?
There also are quite a few Keilwerth trumpets and trombones listed without a serial number. They stand for a few thousand Keilwerth instrument of what I think is their earliest production.
For some instrument there is a more or less reliable date of purchase know. Based on these dates the graph below is made. Note that an instrument bought at a certain time may have waited in the shop for a considerable amount of time, sometimes several years. So drawing a line between the lower dots gives an approximation of the timeline of the production of Keilwerth brass, that is the first 30.000 Keilwerth instruments, which I believe is their own production.
year
Go to Keilwerth brass serial number page:
serial numbers: 0 - 4.999 : 5000 - 9.999 : 10.000 - 14.999 : 15.000 - 335308,
If you note any discrepancies, or have additional information concerning the
Keilwerth history and Keilwerth brass instruments, please
contact me.
Additionally, I would be grateful to anyone who owns a Keilwerth brass
instrument not listed to
contact me with the name, type and serial number (etc.). It would be nice to
build the list also using other horns than those that are being sold.
If you feel any content is in violation of copyright, or for information regarding this site's content, please contact me
Sources
bassic-sax.info/version5/vintage-saxes/european-made-saxes/julius-keilwerth/jk-nauheim
saxwelt.de/index.php/geschichte/keilwerth
www.ebay.de www.ebay.com etc.
Blessing
Links
www.saxpics.com/Keilwerth/index.htm
bassic-sax.info/version5/vintage-saxes/european-made-saxes/julius-keilwerth/jk-nauheim
Arigra, Exakta and other octagonal trumpets
Top action rotary valve trumpets
